product description
The product uses piezoresistive OEM pressure sensor with stainless steel isolation
diaphragm as a signal measuring element, and through computer automated testing, using laser trimming technology for a wide temperature range of zero and sensitivity temperature compensation. Amplifier circuit located within the stainless steel housing, the sensor signal into a standard output signal. The product through rigorous testing of components, semifinished and finished products and aging screening, stable and reliable performance.
Features
· Wide Range Coverage
· All stainless steel structure, pressure port in the form of multi-style, with a flush membrane, sanitary, tantalum diaphragm and other forms of protection IP65
Output signal forms, field adjustable, the scene can be displayed
· Reverse polarity protection and instantaneous overcurrent overvoltage protection, in line with EMI protection requirements
· Explosion-proof products meet the requirements of GB3836.4 standards iaⅡCT6, made explosion-proof certification
· Marine products meet the national "marine electric and electronic products type test procedures" requirement, marine products obtained type approval
· Products have won the national patents, patent No. ZL00226957.0
Product Usage
The product of its excellent reliability, a wide range of adaptability, flexibility and diversity of products, widely used in petroleum, chemical, metallurgy, electric power, hydrological and other industrial process field pressure measurement and control.
